introduce

The function of the SMT PCB Handling Equipment connection station is to connect between SMT production lines. It can also be used for PCB buffering, inspection, testing or manual insertion of electronic components.

The docking station generally includes: a frame and two parallel rotating conveyor belts installed on the frame. The circuit boards are placed on the two conveyor belts for transportation. The existing conveyor belts are generally fixed in position on the frame, so that the two The width of the circuit boards conveyed on the conveyor belt is limited, which is not conducive to conveying circuit boards of different sizes, making the applicability of the docking station low.

According to the function, the connection station can be divided into a connection station with a light frame, a fully automatic connection station, a dust cover connection station, a cold air cover connection station and a screening connection station. All types are used for connection and buffering between machines in the S M T production line and serve as a passing board.

What are the important parameters of the SMT docking station?

⑴. Guide rail length. Usually the length of the connecting platform on the SMT production line is 1 meter or less.

⑵. Width. The width of the docking station is related to the size of the PCB board being transmitted.

⑶. Whether the operating speed and transmission speed meet the connection and transfer requirements are related to the production efficiency of the entire line.

Features

• programmable logic controller
• Hand crank width adjustment
• Standard with inspection sensor and button
• Use stainless steel screw,smooth and parallel width adjustment
• Left to right travel,or right to left,front rail fiexd
• ESD working table
• Height adjustable and stable feet cup location
• Speed control
• SMEMA compatible

Specification

Technical Parameters

Packing

Summary: The connecting station is a device with very low functions and intelligence in the SMT production line, and its structure is relatively simple. Generally speaking, the design of SMT production lines is very compact and reasonable, and it is not necessary to use equipment such as docking stations. If two production lines need to be paralleled, a docking station will be needed to help transfer PCB boards; when the transmission requirements of a certain device in the production line do not meet standards, a docking station can also be used to assist.
