Efficient Automatic PCB Depaneling Equipment Router 0.8-3.0 Bit Diameter Offline Operation

Product Description:

The PCB Depaneling Equipment, also known as the SMT Automatic PCB Cutting Machine, is an innovative and efficient solution designed for the precise separation of PCBs (Printed Circuit Boards) after the completion of the SMT assembly process. This equipment is engineered to handle a variety of PCB designs and sizes, with a focus on maintaining high-quality standards and ensuring the integrity of the electronic components during the depaneling operation.

One of the standout features of the PCB Depaneling Equipment is its capability to manage PCBs with a thickness range of 0.6-4.0mm. This broad range allows for versatility in accommodating different types of PCB materials and designs, making it a suitable choice for a wide array of electronic manufacturing services. The robust construction and precise engineering of the machine ensure that even the thickest PCBs are depaneled with accuracy and minimal stress to the board.

The depaneling machine is equipped with advanced Bit Routing technology, which enables it to efficiently and accurately cut through the PCBs. Bit Routing is a highly precise cutting method that uses specialized routing bits to carve out the desired sections of the PCB. This technology is particularly beneficial for complex PCB layouts where straight-line cuts are not feasible, allowing for a clean and precise separation without damaging adjacent circuits or components.

For PCBs that are scored with the V-Cut method, this PCB Depaneling Equipment provides an exceptional level of precision. V-Cut PCBs have a pre-scored line that guides the separation process, and the depaneling machine is designed to follow these lines with high accuracy, ensuring a clean break without putting undue stress on the board or the components. The V-Cut method is highly efficient and is commonly used for mass production of PCBs, making this depaneling machine an indispensable tool for high-volume electronic manufacturing.

Another significant feature of the SMT Automatic PCB Cutting Machine is its Efficiency Cutting Width, which ranges up to 360mm. This capability enables the machine to process large PCB panels, maximizing throughput and reducing the time required for the depaneling process. With such a wide cutting width, manufacturers can handle larger batches of PCBs, thus improving overall production efficiency.

The PCB Router aspect of the machine allows for the Part Top Height to be up to 40mm (max), providing ample clearance for components mounted on the PCB. This feature is particularly important for assemblies with taller components, ensuring that they are not damaged or compromised during the routing process. The high clearance also means that a broader range of PCB applications can be processed, from simple boards to those with complex, high-profile components.

Reliability is also a key attribute of the PCB Depaneling Equipment, which is exemplified by its use of Schneider relays. Schneider Electric is a renowned brand known for its high-quality and durable electrical components. The inclusion of Schneider relays in the machine's design signifies a commitment to reliability and long-term performance. These relays ensure consistent operation of the machine, with minimal downtime due to equipment failure, thus providing users with peace of mind and reduced maintenance costs.

In summary, the PCB Depaneling Equipment is a state-of-the-art machine that combines Bit Routing, V-Cut compatibility, and PCB Router functionalities to offer a comprehensive solution for PCB separation. Its ability to handle a thickness range of 0.6-4.0mm, an Efficiency Cutting Width of up to 360mm, and a Part Top Height of up to 40mm, along with the reliability provided by Schneider relays, makes it an exceptional addition to any electronic manufacturing setup looking to enhance productivity, maintain quality, and ensure the safety of PCB assemblies during the depaneling process.

Features:

• Product Name: PCB Depaneling Router
• Part Top Height: 40mm(max)
• Air Pressure: No
• Depaneling Blade: High Quality Guillotine Blade
• Other Name: SMT Automatic PCB Cutting Machine
• Power: 60W
• Feature: Bit Routing

Technical Parameters:

Applications:

The HSTECH RT-330 PCB depaneling equipment, originating from China and boasting CE certification, has been meticulously crafted for precision and reliability in the electronics manufacturing industry. This machine is designed to facilitate the separation of PCBs (Printed Circuit Boards) by employing a process known as 'Bit Routing' – a method that ensures clean and precise cuts along the board's predetermined lines.

The RT-330 model is ideal for a variety of applications and scenarios where PCBs are used. For instance, in the production of consumer electronics such as smartphones, laptops, and tablets, where the precision of component placement and the integrity of the circuitry are paramount, the RT-330's bit routing capability ensures that each board is depaneled with the utmost accuracy, thereby minimizing the risk of damage to components and ensuring the functionality of the final product.

With a minimum order quantity of just one unit and a supply ability of 50 sets, this PCB depaneling equipment is not only accessible to large-scale manufacturers but also to smaller operations that require high-quality depaneling solutions. The HSTECH RT-330 comes with a 1-year warranty and features a 60W power system with an adjustable separating speed, ensuring that operators can calibrate the process according to specific production requirements. The separating width is also adjustable from 1 to 100mm, providing versatility for different sizes of PCBs.

Manual loading is a feature of this model, which allows for the careful handling of each individual PCB. This is particularly important for prototypes or small batch production where the value of each board is significant. The packaging details include a sturdy wooden case, which ensures the machine is delivered safely and securely to the customer within the 3-week delivery time frame. Payment terms are straightforward with TT (Telegraphic Transfer), and this, combined with the robust support and service, makes the investment into the HSTECH RT-330 a sensible choice for businesses looking to streamline their PCB depaneling process.

The versatility of the RT-330's bit routing system further extends to specialized industries such as aerospace, medical devices, and automotive electronics, where the precision and reliability of electronic components are critical. In these sectors, the RT-330 can be integrated into the production line to ensure that even the most complex PCBs are depaneled with precision, maintaining the high standards required for these demanding applications.

In summary, the HSTECH RT-330 PCB depaneling equipment is a powerful, versatile, and reliable solution for a wide range of industries requiring high-precision bit routing to separate PCBs. With adjustable features, manual loading capabilities, and a dependable service framework, it represents an essential tool for any electronics manufacturer seeking to optimize their depaneling process and maintain the highest quality standards in their products.

Customization:

Brand Name: HSTECH

Model Number: RT-330

Place of Origin: China

Certification: CE

Minimum Order Quantity: 1

Packaging Details: Wooden

Delivery Time: 3 weeks

Payment Terms: TT

Supply Ability: 50 sets per month

Other Name: SMT Automatic PCB Cutting Machine

Loading: Manual

Separating Speed: Adjustable

Separating Width: 1-100mm

Warranty Year: 1 Year

Experience precision and efficiency with HSTECH's RT-330, a high-performance PCB Router designed for seamless Bit Routing . This SMT Automatic PCB Cutting Machine, originating from China with CE certification, ensures quality and reliability. With a minimum order quantity of just one unit and a supply ability of 50 sets per month, this equipment is ready to meet your PCB depaneling needs. The RT-330 model boasts features such as manual loading, adjustable separating speed, and a separating width range of 1-100mm, catering to various PCB designs and requirements. Each PCB depaneling equipment is carefully packaged in wooden crates to ensure safe delivery within 3 weeks upon receipt of TT payment. HSTECH's commitment to excellence is further underscored by a 1-year warranty, providing you with peace of mind and support. Enhance your manufacturing process with the robust and precise Bit Routing capabilities of the RT-330 PCB Router.
