600mm length Touch Screen SMT PCB Conveyor AC220V With Motor

600mm length Touch Screen SMT PCB Conveyor AC220V With Motor
600mm length Touch Screen SMT PCB Conveyor AC220V With Motor 600mm length Touch Screen SMT PCB Conveyor AC220V With Motor 600mm length Touch Screen SMT PCB Conveyor AC220V With Motor

Large Image :  600mm length Touch Screen SMT PCB Conveyor AC220V With Motor

Product Details:
Place of Origin: China
Brand Name: HSTECH
Certification: CE
Model Number: HS-C600S
Payment & Shipping Terms:
Minimum Order Quantity: 3 sets
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 10~14 days
Payment Terms: T/T, Western Union, MoneyGram, D/P
Supply Ability: 500 pcs per month
Detailed Product Description
Product Name: Link Conveyor Other Name: SMT Conveyor
Conveyor Length: 600mm Or Specify Transport Belt: Green Color ESD Belf
Belt Thickness: 1.0 Mm Voltage: 1P AC 110V/220V 50/60HZ
Warranty: 1 Year Packing: Wrap, Wooden Box
High Light:

Touch Screen SMT PCB Conveyor

,

600mm Length SMT PCB Conveyor

,

AC220V SMT Link Conveyor

Automatic Width Adjust with Motor Touch Screen Control SMT PCB Conveyor



Specification



Model HS-C600S
Power Supply AC220V or AC110V 50/60Hz
PCB Size 50*50~500*390mm
Width adjustment Motor adjustment
PCB Direction Left to right or right to left
Transmission Height 900 ± 20 mm
Transmission Speed 0.5-20 meters per minute adjustable
Track fixed side front side fixed( or back side fixed for option)
Machine Length 0.5M/0.6M/0.8M/1M/1.5M
Options Light,Fan,Magnnifying,Cover,Inspection
Communication signal SMEMA



Features



1, Touch screen control.

2, Motorized width control.

3, 600mm length or customization.

4, Stable machine structure, made of stainless steel.

5, Standard 390mm PCB width, hand crand width adjustment.

6, Inspection function by button.

7, Optional dust cover, tower light lamp, two section control, etc.

8, Customized requirement available.

9, SMEMA signal for inline connection.

600mm length Touch Screen SMT PCB Conveyor AC220V With Motor 0

600mm length Touch Screen SMT PCB Conveyor AC220V With Motor 1

600mm length Touch Screen SMT PCB Conveyor AC220V With Motor 2





600mm length Touch Screen SMT PCB Conveyor AC220V With Motor 3
