Tabletop XYZ High Speed CCD Screw Fastening Machine 360 Constant Control System

This PCB Flipper Inverter is a professional automated handling device specially designed for SMT production lines. It realizes fully automatic 180-degree inversion of printed circuit boards to support double-sided assembly, soldering and inspection processes.

Equipped with reliable PLC control system and stable transmission structure, the PCB Flipper Inverter runs smoothly during board flipping. It supports independent flip mode and direct pass mode, which can be switched freely according to production demands. With standard SMEMA interface, the equipment can seamlessly connect with other upstream and downstream SMT machines to form a continuous automated production line.

The whole machine adopts compact industrial design, features enclosed protective structure and humanized operation panel. It effectively replaces manual board turning, avoids component damage and board deformation caused by human operation, and becomes essential handling equipment for modern electronic manufacturing workshops.

• The equipment and its parts are new and unused.
• The overall noise of the equipment is <70dB (1m from the equipment).
• Machinery and equipment conform to the relevant standards of China or international standards acceptable to the user.
• Electrical equipment should comply with IEC standards or international standards acceptable to the user.
• Supporting equipment and test instruments and meters are measured using IsO international standard units of measurement.
• Air pressure: 0.4MPa~0.8MPa, air quality is DINISO 8573-1 Grade 3 standard.
• Temperature: 18℃~30℃, humidity: 30%~70%.
• Working system: 24 hours operation/day*7 days.

The PCB Flipper Inverter is widely used in all kinds of electronic manufacturing industries and SMT automated production lines.

1. Double sided PCB assembly, soldering and reflow processes
2. PCB inspection, testing and rework stations
3. Consumer electronics production lines
4. Communication equipment and automotive electronics manufacturing
5. Household appliances and industrial control circuit board processing
6. Small batch trial production and large scale mass production workshops

• Maximize Production Uptime: Built with industrial-grade components and precision servo/stepper motors to guarantee 24/7 stable operation and minimal maintenance.
• Protect Product Yield: Advanced ESD-safe materials and soft-clamping technology drastically reduce the risk of micro-cracks or component shifting during the flipping process.
• Cost-Effective Automation: A highly reliable, budget-friendly solution to replace manual labor, reducing operational costs and human error.
• Custom Engineering Support: We offer tailored modifications (e.g., wider rails, specialized clamps, or custom conveyor heights) to perfectly match your unique factory layout and specific PCB requirements.

Don't let manual board handling slow down your high-speed production line. Upgrade to our premium PCB Flipper Inverter and experience the perfect balance of speed, precision, and reliability.

Contact us now for a customized quote, detailed technical datasheet, or to schedule a live video demonstration of our automated PCB handling solutions!
